JL Audio
JL Audio 10" W3 SUBWOOFER 500W @ 2 OHM JL10W3V3-2
JL Audio 10" W3 SUBWOOFER 500W @ 2 OHM JL10W3V3-2
Couldn't load pickup availability
10" W3 SUBWOOFER 500W @ 2 OHM
JL10W3V3-2
W3v3 10-inch Subwoofer (500 W, 2 Ω)
This acclaimed Subwoofer strikes an outstanding balance in power handling, enclosure requirements and excursion to deliver excellent results in medium power applications. Several exclusive JL Audio technologies and proprietary assembly techniques are applied to the 10W3v3 to enhance linearity and reliability.
The 10W3v3-2 is best used with amplifier power in the 150W - 500W range and is optimized to operate in a compact 0.625 cu. ft. (17.7 l) sealed enclosure, or a 1.25 cu. ft. (35.4 l) ported enclosure.
| Speaker Size (in) | 10" |
|---|---|
| Style | Round |
| Impedance (Ohms) | 2 |
| Voice Coils | Single |
| RMS Power (W) | 300 |
| Peak Power (W) | 500 |
| Sensitivity (dB @ 1W/1m) | 85.37 |
| Frequency Response (Hz) | N/A |
| Features | DMA Optimised Motor Elevated Frame Cooling FCAM™ Cone Attach Method Vented Reinforcement Collar Insert Moulded Sub-Assembly Engineered Lead-Wire System Customisable Trim Ring Constructed In USA |
| Height (cm) | 26.7 |
| Width (cm) | 26.7 |
| Depth (cm) | 17.1 |
| Protrusion (cm) | 2 |
| Mounting Depth (cm) | 15.1 |
| Mounting Hole Diameter (cm) | 23 |
| Grills | JLSGRU-10 (Sold Separately) |
| Recommended Amplifier | JLJD500/1 JLRD500/1 JLMX500/1 |
| Recommended Minimum Power Handling (W) | 150 |
| Recommended Maximum Power Handling (W) | 500 |
| Recommended Box Volume Sealed (Litres) | 17.7 |
| Recommended Box Volume Ported (Litres) | 35.4 |
| Brand | JL Audio |
| EAN | 699440990486 |
