EDGE 2000W RMS 12" SUBWOOFER HIGH POWER BASS CAR AUDIO SPL NEW MODEL Dual 2 Ohm

Edge EDX12D2-E3 Xtreme Series 12 inch 2000 watts Subwoofer

Introducing from EDGE the Xtreme series subwoofers, for those looking for deep, high power, street thumping bass our subwoofers are for you, multiple models and sizes available complete with a brand new range.

Introducing from EDGE the Xtreme series subwoofers, for those looking for deep, high power, street thumping bass our subwoofers are for you, multiple models and sizes available complete with a brand new range.

Our Xtreme series subwoofers were designed with a combination of street bass and competition bass in mind. All the subwoofers feature massive triple stacked motor structures across 3 baskets types all constructed from bast aluminium for strength and rigidity, paired with Polycotton spiders, stitched tinsel leads, non pressed paper cones and 3 inch Voice coils we have a variant of power and sizes available.

The new for 2023 feature a brand new custom tooled basket for increased excursion on the low bass and an even wider foam surround to cope with this excursion! This is paired with our brand new custom tooled 2 piece dustcap giving us a unique subwoofer!

If Pushing the limits of excursion and SPL our Xtreme series subwoofers have been designed with you in mind!

Model: EDX12D2-E3

Cone: Non pressed paper cone

Surround: Big roll foam - dual stitched

Voice Coil Former: 3" Black Aluminium

Spider: 3pcs Black PC

Gasket: Rubber

Top Plate: 15mm Black anodized

T-Yoke: 15mm Black anodized flat

Terminal / Wire: Spring loaded connectors

Impedance: Dual 2 Ohms

RMS Power: 2000 watts

Equivalent Volume - Vas: 20.2L

Free Air Resonance - Fs: 33Hz

Mechanical Factor - Qms: 6.238

Electrical Factor - Qes: 0.529

Total Factor - Qts: 0.488

Moving Mass - Mms: 338g

Compliance - Cms:   67.19μ M/N

BI Factor - BI: 21.97 T

Voice Coil Inductance - Le:   158 mH

Diaphragm Area - Sd:   459CM2

DC Resistance - Re:   2*1.8 Ω

SPL: 84dB

Magnet: 190mm x 95mm x 20mm 3pcs

Overall Diameter: 286mm

Mounting Depth: 196mm
